路拌機是如何進行工作的？
來源：http://www.beianedu.cn/ 日期：2023-06-30
穩定土拌和機俗稱：路拌機，是一種自行式全液壓穩定土拌和設備，可對二灰土、二灰碎石、水穩沙礫等各種不同配比材料進行就地拌和，并可對舊瀝青路面進行銑刨。那么路拌機是如何進行工作的？下面冷再生機租賃廠家為您講解：
The stabilized soil mixer, commonly known as the road mixer, is a self-propelled fully hydraulic stabilized soil mixing equipment that can mix various materials with different proportions such as lime soil, lime crushed stone, water stabilized sand and gravel on site, and can also mill old asphalt pavement. So how does the road mixer work? Below, the manufacturer of the cold regeneration machine rental will explain to you:
行走與拌和轉子的驅動均為全液壓閉式回路。行走速度與拌和轉子轉速均可實現無級變速輔助系統（轉向、拌和轉子升降、尾門開閉）均為液壓操縱。
The driving of both the walking and mixing rotors is a fully hydraulic closed circuit. Both the walking speed and the mixing rotor speed can achieve stepless speed change assistance systems (steering, mixing rotor lifting, tailgate opening and closing), all of which are hydraulically operated.
通過壓力自動補償裝置（POR系統）實現功率自動分配儀表面板布置合理，全面顯示工作狀態帶防翻保護架的密封式駕駛室、豪華型司機座椅，并配帶空調設備，以改善駕駛員的作業環境低壓寬基人字形花紋驅動輪胎，抗振性能優良。
By using the pressure automatic compensation device (POR system) to achieve power automatic distribution, the instrument panel layout is reasonable, fully displaying the working status of the sealed cab with anti roll protection frame, luxury driver seat, and equipped with air conditioning equipment to improve the driver's working environment. Low pressure wide base herringbone pattern drive tires have excellent vibration resistance performance.
附著牽引力大整體式前橋及SOMA后橋可靠性高大滾筒工作轉子，提高了工作效率，確保了拌和質量，并可根據用戶需要配置水噴灑裝置及銑刨轉子。
The integrated front axle and SOMA rear axle have high reliability and high drum working rotor, which improves work efficiency and ensures mixing quality. Water spraying devices and milling rotors can be configured according to user needs.
此外在進行路拌機維修的時候，應該注意：
In addition, when repairing the road mixer, attention should be paid to:
(1)檢查路拌機有無傷痕和銹蝕現象，必要時應更換新品。
(1) Check the road mixer for scratches and rust, and replace it with a new one if necessary.
(2)檢查路拌機副配合情況。將柱塞端頭插人柱塞套內，傾斜約60°，若柱塞能在自身作用下緩慢地下滑為配合良好。
(2) Check the coordination of the road mixer. Insert the end of the plunger into the plunger sleeve and tilt it at about 60 °. If the plunger can slowly slide under its own action, it is considered a good fit.
(3)檢查路拌機柱塞副的密封性。用手握住柱塞套，兩個手指堵住柱塞頂端和側面的進油口。用另一只手拉出柱塞，感到有較大的吸力，放松柱塞立即縮回原位，表明柱塞副密封良好，否則應更換柱塞副。
(3) Check the sealing of the plunger pair of the road mixer. Hold the plunger sleeve with your hand and block the oil inlet at the top and side of the plunger with two fingers. Pull out the plunger with the other hand and feel a strong suction. Release the plunger and immediately retract it back to its original position, indicating that the plunger pair is well sealed. Otherwise, the plunger pair should be replaced.
(4)檢查出油閥副減壓環帶是否磨損有臺階或傷痕現象，必要時應予以更換。
(4) Check if the pressure reducing ring of the oil outlet valve is worn, stepped or scratched, and replace it if necessary.
若是一些自己無法解決的故障問題，在沒有完全把握解決故障的情況下，澳托士建議盡量尋找專業的維修廠家http://www.beianedu.cn，以免自己動手造成不必要的損失。
If there are some fault problems that cannot be solved by oneself, and we are not fully confident in solving the problem, Austros recommends seeking professional repair manufacturers as much as possible http://www.beianedu.cn To avoid unnecessary losses caused by hands-on actions.
